Runtime

Local daemon

clumsiesd is an owner-scoped macOS launchd service. The macOS app installs and starts it, while both the app and MCP connect to the same process over XPC. The daemon has one central SQLite database for durable client state and one derived search database inside each Project's active local storage.

The database currently stores:

• installation identity and schema version
• Server URL and selected project configuration
• canonical local Project bindings from Server authority plus workspace root to project_id
• local drafts and ordered operations
• synchronization status, failures, and Server draft identity
• immutable Blob, Tree, and Commit metadata
• installed organization and project Refs
• the active search head and storage-location revision for each Project

Each Project search database stores its derived search revisions, complete Effective Memory resources, Markdown units, FTS5 rows, and vectors. Embedding and reranking models remain in the shared daemon cache and are not copied per Project.

File permissions are owner-only. Access and refresh tokens are stored as one Server-bound generic-password item in macOS Keychain. SQLite never persists either token, and daemon has no plaintext credential fallback.

Desktop request path

The native Swift client serializes typed capability requests over XPC. Daemon executes local operations or sends authenticated HTTP requests to Server.

SwiftUI/AppKit -> XPC -> daemon -> HTTPS -> Server

This keeps credentials in daemon and macOS Keychain without a WebView or CORS dependency.

Draft synchronization

Every local operation is persisted before synchronization is attempted. The queue supports create, update, rename, delete, and discard for Context, Rule, and Workflow resources.

Deleting an authoritative resource keeps an open deletion Draft until Review merge. Deleting a resource created only by the current Draft cancels that creation instead: daemon records a discard, and the Draft leaves Effective Memory without creating a deletion proposal for a resource that never existed in the Ref.

Each draft carries:

• project_id
• scope (org or project)
• resource kind
• base_commit_id
• the currently installed target Ref Commit
• derived freshness and Server reconciliation projection
• local draft ID and optional Server draft ID
• ordered operation history

The sync worker starts automatically, wakes when a new operation arrives or configuration changes, and retries failed work. A local draft is reused across successive edits, so repeated writes do not create one Server draft per keystroke.

MCP write path

MCP keeps the public store(resource, op) tool shape. Internally it adds the current bound project ID and project scope before sending the operation to daemon. At process startup, MCP gives its current working directory to daemon; daemon canonicalizes the path and resolves the nearest bound ancestor in SQLite. MCP never treats a legacy Workspace ID as a Project ID. The Rust daemon test suite consumes a literal Zig MCP envelope to keep that cross-language contract executable.

Agent-originated updates are exact text replacements, not complete-document writes. MCP forwards the resource ID, the complete-resource hash returned by load, and one or more old_text/new_text pairs. While draft and commit sync are excluded, daemon resolves the current Effective Memory resource, verifies the hash and unique non-overlapping matches, and applies the complete batch atomically. Only the materialized complete result is persisted as the ordinary Draft update operation, so Server synchronization and Commit storage remain independent of the agent-facing editing protocol.

An old ~/.clumsies/config.toml entry is used only when no daemon binding exists. MCP matches its display name against the signed-in user's Server Projects, persists the unique canonical project_id in daemon, and removes the migrated path from the old file. Missing or duplicate matches fail explicitly; the legacy ws_id value is never sent to daemon.

When the caller omits base_commit_id, daemon reads it from the installed project Ref before creating the local draft. A missing Ref produces a draft with no base; daemon never invents a Commit ID.

MCP does not currently expose organization scope in store; interpreting the same call as a Hub write would be ambiguous. Hub writes are explicit in Desktop.

The daemon combines the installed authority generation with current open/submitted Draft operations before both activate and load. For a resource with a Draft, it restores that resource from the Draft Base Commit, applies the ordered operations, and overlays the complete Draft result on the latest installed authority. All other resources come from the latest Commit. This applies equally to create, update, rename, and delete. A successful store therefore changes the next Effective Memory hash and causes the next activation to build or select a matching search revision.

Synchronization and reconciliation

Draft sync and Commit sync are independent. Commit sync may update the local Ref, current_commit_id, freshness, and candidate validity, but it never changes a Draft Base, operations, content, or lifecycle. A behind Draft remains editable, syncable, restart-safe, and visible to MCP.

Server is the canonical reconciliation executor. A candidate binds Draft ID, Draft version, Base Commit, and current Commit, and is either clean or conflicts. Merely creating or viewing it does not mutate the Draft. Explicit rebase stores the previous Draft revision and rewrites the Draft as base = Current plus operations = diff(Current, confirmed result). Any Draft edit or Ref advance invalidates the old candidate.

Commit synchronization

The daemon synchronizes both organization and project Refs on its background interval and through explicit retry. Its target set is the union of durable directory bindings, active Draft Projects, and the Project currently selected by Desktop. Desktop selection is UI state and cannot redirect an MCP process in another directory.

Server commit-state + ETag
  -> validate Ref identity
  -> download Commit payload
  -> verify Blob addresses and Tree ownership
  -> build an immutable project generation
  -> move the local SQLite Ref
  -> daemon combines that generation with local Drafts
  -> MCP asks daemon to activate fragments or load complete resources

Before moving a local Ref, every sync also checks active open and submitted Drafts and fetches any missing Base Commit, Tree, and Blob payloads referenced by their base_commit_id. This preserves an old-Base overlay after a cache rebuild without pinning the rest of the project to that Base.

The generation is built under a temporary directory and renamed before the Ref transaction commits. A failed download, invalid payload, or incomplete generation leaves the previous Ref and MCP-visible files unchanged. The commit_sync.server_cursor is the installed project Commit ID, not a fabricated timestamp or independent revision.

Server currently publishes full Commit payloads, so incremental object transfer is not implemented. Cached immutable objects are retained for restart and integrity checks. Active Draft Base references are retention roots and cannot be garbage-collected.

Cache diagnostics preserve layer boundaries: an unknown local Ref reports project_ref_not_synced; an absent or invalid materialized generation reports commit_generation_missing or commit_generation_corrupt; only derived search index preparation and build failures use search-index error codes.

Project local storage

Project Local Storage is an installation-local cache setting keyed by normalized Server authority and canonical project_id. It is not part of Server Project metadata and is not synchronized to another installation. An absent setting resolves to <daemon-cache>/projects/<authority-hash>/<project-id>. A preexisting projects/<project-id> generation is adopted once into that authority-scoped layout with its permissions hardened; daemon does not maintain both layouts.

For a custom location, the selected directory is only a parent. Daemon owns the following subtree and never treats it as an editable working directory:

<selected-root>/.clumsies/cache-v1/<authority-hash>/<project-id>/
  ownership.json
  generations/
  search/index.sqlite
  staging/

Changing the location creates a persistent daemon move. Daemon materializes and verifies the generations and Project search index under destination staging, then switches the location with expected_location_revision CAS while holding the same synchronization boundary used by Commit installation. Readers retain the old location until the switch obtains its write gate. A restart resumes any nonterminal move; cleanup failure after a successful switch is diagnostic and does not roll back the new active location.

The macOS app uses NSOpenPanel to create a one-time ordinary bookmark for the selected directory. Daemon resolves that handoff while Desktop is running, creates a security-scoped bookmark under the daemon's own code-signing identity, and persists only that daemon-owned bookmark. This is required because an app-scoped bookmark created by Desktop cannot be resolved by a separately signed LaunchAgent. Daemon holds security-scoped access for each filesystem operation and refreshes stale persisted bookmark data. It refuses network filesystems, symbolic links, invalid ownership markers, unsafe nesting, and paths without capacity or write access. Managed directories and files use 0700 and 0600.

An unavailable custom location never falls back to the default cache or advances the local Project Ref without a complete generation. Drafts, operation queues, and their synchronization continue in central SQLite. activate, load, and checkout return an explicit storage/search readiness error until the same location becomes available again.

The daemon IPC methods are project_storage, replace_project_storage, project_storage_move, reset_project_storage, and clear_project_cache. Clear Cache removes only marker-owned generations, search data, and staging; Drafts, settings, models, and files outside the managed subtree are preserved.

Diagnostics

Desktop can read daemon health, bootstrap state, project configuration, sync status, MCP status, draft lists, draft details, and operation results through typed XPC requests. It can request explicit retry without directly mutating queue rows.

The native Diagnostics window has separate Runtime and Retrieval pages. Retrieval lists the active Project's latest Runs and loads one complete trace on demand. Candidate columns show exact/BM25, vector, RRF, reranker, final rank, score, exclusion reason, and activation delta action. A successful Run can be added to the local Evaluation Set, graded from 0–3, supplemented with missed resource evidence, exported as a versioned fixture, or retained while unpinned history is cleared.

The local methods are list_retrieval_runs, get_retrieval_run, create_evaluation_case, replace_evaluation_judgments, clear_retrieval_runs, and export_evaluation_set. Retrieval history is central daemon state and remains independent from Project Local Storage. Retention keeps the latest 500 unpinned Runs per Project; Evaluation Cases pin their source Runs and immutable corpora. See docs/retrieval-evaluation.md.

Server diagnostics are available at /api/v1/admin/health. Database, schema, Commit service, and OIDC are reported as separate components.
